Basic Level For Freshers --- 1 Month (40 Hrs)

• Schematic, Symbol creation and assigning, netlist creation & Importing,

• Board outlines with shapes/cutouts

• PTH & S/S Board Layout/Finalisation,

• Gerber Creation

Proficient Level ---- 80 Hrs

• Schematic, Symbol creation and assigning, netlist creation & Importing,

• Board outlines with shapes/cutouts PTH & S/S Board Layout/Finalisation,

• Cross Probing of schematic and Layout

• Board Placement & Routing Aspects for better board fuctionality

• Assigning/Defining of GND/Power Tracks to Planes

• Gerber Creation with drill, Fab, DXF and BoM files.

Advanced Level ----

• Simulation, Signal integrity, Cross Talk,DDR1 to DDR3

• Impedance Matching, Length Matching, Differential signals

• Creating classes and its clearances

• Analog, Digital, Power, mixed i.e. section wise placements creating planes

• Assigning nets to planes, cross-probing

• Assigning and defining GND POWER PLANES for Multi-Layer Boards

• Via selection, assigning different trace widths as per signal requirement

• Different routing techniques and planning for constraint signals

• Adding small planes and stitching vias

• Library management and maintenance

• Implementing ECOs, Design Clean-up and finishing

• Setting Layers and Stack-up

• Creating panelization and break-away for Fab

• Hands on practice on real industry projects

Embedded C Course:

• Basic Atmel 8051 Core with Keypad/7Seg/LCD/eeprom/RTC/ADC/Stepper Mo-tor/Relay Interface.

• Intermidiate PIC24F (64 PIn)Based Keypad/7Seg/LCD/eeprom/RTC/ADC/Stepper Motor/Relay Interface.

• Advanced PIC24F Based Application with USB Host Application/Raspberry Interface /TFT Interface/Camera Interface/Audio Interface.

• Architecture,Programming and Interface

• Setting Keil MDK 420 Compiler Development Environment6. Free Hardware Board

• Free Hardware Board

Features:

• Individual Training

• Flexible Hours OR Weekend Batches

• Corporate Training Programmes(Custom Designed as per Re-quirements)

• Group Booking Discounts available

• Revision of Basic Electronics for Freshers

• Apprenticeship available
